PADDY SEPARATOR
Introduction:
- For (BG): To gain the above-mentioned capacity, the rate of paddy mixed in brown rice should not exceed 10% and the moisture should not exceed 15%.
- For (BGM): To gain the above-mentioned capacity, the maximum rate of 75 paddy grains per kilogram mixed in polished rice, and the moisture less than 15% will produce finished rice whose rate of paddy is less than 15 paddy grains per kilogram.
The utility of the minor tray:
It is used to separate the eliminated-paddy once again in order to reduce the rate of rice mixed in the eliminated-paddy.
Features:
- The tray is made of stainless steel with vertically triangle-shaped waves. The bran cannot stick to the wallet during use.
- High paddy separation effciency, paddy can be separated from mixture in high moisture.
- The machine will automatically stop when short of material (to avoid the increase of paddy running over the finished rice).
- Working quickly in manual mode at the last stage of each batch.
| Model | Input Capacity (Ton/hour) | Req. Power | RPM | Net weight | Dimensions (L x W x H) |
| Gạo lức | HP | Kg | mm | ||
| BG-14C | 2.5 - 3.5 | 2 | 260 - 280 | 799 | 2440 x 2100 x 2850 |
| BG-18C | 3.2 - 4.5 | 2 | 260 - 280 | 830 | 2440 x 2100 x 3010 |
| BG-20C | 3.6 - 5 | 2 | 260 - 280 | 845 | 4620 x 2840 x 3090 |
| BG-22C | 4 - 5.5 | 2 | 260 - 280 | 860 | 4900 x 2900 x 3130 |
| BG-24C | 4.3 - 6 | 2 | 260 - 280 | 875 | 4150 x 2350 x 3170 |
| BG-32C | 6.5 - 9.6 | 5 | 250 - 270 | 2600 | 3200 x 2860 x 4100 |
| BG-40D | 8 - 12 | 5.5 | 250 - 270 | 2890 | 3200 x 2860 x 4450 |
